RuneAudio+R e4

Raspberry Pi related support

Re: RuneAudio+R e4

Postby R101 » 27 Jul 2020, 20:52

klassikmann wrote:
RolandBlaze wrote:
R101 wrote:@rern,

The latest update is working well for me, but the problem of having to choose whether to have the volume control or the cover art on the playback page is still there. If I disable the cover art, the disabled volume control appears.


yup have this also.

@R101 @RolandBlaze
To assist rern in identifying the problem, please post your playback settings.
Here a mine (both volume control and coverart are present (plus time):
Checked are: "Time", "WebRadio elapsed", "Cover art", "Volume"

klassikmann


My playback settings:

MPD settings have no volume enabled and mixer disabled.
(Pi 3B, RuneAudio+R e4, JLS I2S over USB)
R101

Posts: 292
Joined: 29 Apr 2016, 16:16

Re: RuneAudio+R e4

Postby rern » 28 Jul 2020, 13:51

R101 wrote:...
The latest update is working well for me, but the problem of having to choose whether to have the volume control or the cover art on the playback page is still there. If I disable the cover art, the disabled volume control appears.
...

Please tell what would be the layout you try to set.

rern
Raspberry Pi 3B > SMSL M8 DAC
Raspberry Pi Zero W
Raspberry Pi 4B
GitHub
User avatar
rern

Posts: 602
Joined: 14 Jul 2016, 08:15

Re: RuneAudio+R e4

Postby Sn4kY » 28 Jul 2020, 17:12

Hi.

i've just download and install a fresh copy of RA+Re4

When I switch on the UPnP feature, it fallback to off.

there are some details :

Code: Select all
● upmpdcli.service - UPnP Renderer front-end to MPD
     Loaded: loaded (/usr/lib/systemd/system/upmpdcli.service; enabled; vendor preset: disabled)
    Drop-In: /etc/systemd/system/upmpdcli.service.d
             └─override.conf
     Active: activating (auto-restart) (Result: exit-code) since Tue 2020-07-28 18:00:43 CEST; 25s ago
    Process: 3159 ExecStart=/usr/bin/upmpdcli -c /etc/upmpdcli.conf (code=exited, status=127)
   Main PID: 3159 (code=exited, status=127)


If I try to exec in SSH :
Code: Select all
root@runeaudio+R e4:~ # /usr/bin/upmpdcli -c /etc/upmpdcli.conf
/usr/bin/upmpdcli: error while loading shared libraries: libjsoncpp.so.22: cannot open shared object file: No such file or directory


I have installed jsoncpp but without no changes

I think the upmpdcli don't search the good lib :
Code: Select all
root@runeaudio+R e4:~ # ldd /usr/bin/upmpdcli | grep json
        libjsoncpp.so.22 => not found

Code: Select all
ls -alh /usr/lib/libjsoncpp.so*
lrwxrwxrwx 1 root root   16 Jul 19 21:22 /usr/lib/libjsoncpp.so -> libjsoncpp.so.24
-rwxr-xr-x 1 root root 178K Jul 19 21:22 /usr/lib/libjsoncpp.so.24


Okay, well, trying to symlink...
Code: Select all
cd /usr/lib/
ln -s libjsoncpp.so libjsoncpp.so.22

and restarting...

Good job !
Code: Select all
upmpdcli.service - UPnP Renderer front-end to MPD
     Loaded: loaded (/usr/lib/systemd/system/upmpdcli.service; enabled; vendor preset: disabled)
    Drop-In: /etc/systemd/system/upmpdcli.service.d
             └─override.conf
     Active: active (running) since Tue 2020-07-28 18:10:37 CEST; 52s ago
   Main PID: 5287 (upmpdcli)
      Tasks: 10 (limit: 2140)
     CGroup: /system.slice/upmpdcli.service
             └─5287 /usr/bin/upmpdcli -c /etc/upmpdcli.conf



Maybe other people will have this bug ?
Sn4kY

Posts: 3
Joined: 11 Oct 2018, 08:06

Re: RuneAudio+R e4

Postby klassikmann » 28 Jul 2020, 17:39

Update Re4 20200728

The problem with thumnails in the coverart view is still present.

klassikmann
klassikmann wrote:
klassikmann wrote:Update Re4 20200726

The thumbnails in the coverart library view are missing. The entries are present and it's also possible to click on an invisible coverart to select an album.

Edit: After some clicking back and forth the thumbnails are back again.

Edit 2: Some clicks later the thumbnails are gone again, ..., and come back again.

klassikmann

An Observation:
If the thumbnails are invisible in the coverart view, I select an album as a new playlist and the thumbnails are back again. Clearing the playlist and refreshing the browser window (F5) and the thumbnails vanish. Tested with Firefox and Chrome.

klassikmann
RPI 3B + HifiBerry Digi+ Pro + RuneAudio+R e4
klassikmann

Posts: 158
Joined: 27 Apr 2016, 18:36

Re: RuneAudio+R e4

Postby R101 » 28 Jul 2020, 17:41

rern wrote:
R101 wrote:...
The latest update is working well for me, but the problem of having to choose whether to have the volume control or the cover art on the playback page is still there. If I disable the cover art, the disabled volume control appears.
...

Please tell what would be the layout you try to set.

rern


As in the screenshot above, rern. If I untick the cover art, the volume control appears. The volume option is greyed out and cannot be changed. Volume is turned off in the bit-perfect setting.
(Pi 3B, RuneAudio+R e4, JLS I2S over USB)
R101

Posts: 292
Joined: 29 Apr 2016, 16:16

Re: RuneAudio+R e4

Postby AndyF » 29 Jul 2020, 17:49

klassikmann wrote:Update Re4 20200728

The problem with thumnails in the coverart view is still present.

klassikmann
klassikmann wrote:
klassikmann wrote:Update Re4 20200726

The thumbnails in the coverart library view are missing. The entries are present and it's also possible to click on an invisible coverart to select an album.

Edit: After some clicking back and forth the thumbnails are back again.

Edit 2: Some clicks later the thumbnails are gone again, ..., and come back again.

klassikmann

An Observation:
If the thumbnails are invisible in the coverart view, I select an album as a new playlist and the thumbnails are back again. Clearing the playlist and refreshing the browser window (F5) and the thumbnails vanish. Tested with Firefox and Chrome.

klassikmann


Hi klassikmann,

on my system, coverart-view works fine on every browser. Maybe there's a "problem"-thumbnail in your folder?
I would try to temporarly move them in a different folder and move them back step-by-step until error occurs.

regards, Andy
AndyF

Posts: 143
Joined: 02 Aug 2015, 07:36
Location: Germany - Bavaria

Re: RuneAudio+R e4

Postby klassikmann » 29 Jul 2020, 18:42

Hallo Andy,

thank you for your information about the non-existence of the problem in your environment. I'm doubtful whether the problem is specific to my installation or a general one. I have about 2000 coverarts so that it is rather time consuming following your proposal ("I would try to temporarly move them in a different folder and move them back step-by-step until error occurs."). What I just did is to restore an old backup and the problem persists.

Hm?

klassikmann
RPI 3B + HifiBerry Digi+ Pro + RuneAudio+R e4
klassikmann

Posts: 158
Joined: 27 Apr 2016, 18:36

Re: RuneAudio+R e4

Postby AndyF » 29 Jul 2020, 19:22

Hallo klassikmann,

maybe it's possible to copy them in alphabetical steps? I've got only 350 thumbnails with following access rignts:
-rw-r--r-- http:http

Only .jpg's are inside. But I don't have much songs with special characters in its name ...


regards, Andy
Last edited by AndyF on 29 Jul 2020, 19:37, edited 2 times in total.
AndyF

Posts: 143
Joined: 02 Aug 2015, 07:36
Location: Germany - Bavaria

Re: RuneAudio+R e4

Postby klassikmann » 29 Jul 2020, 19:27

Hi Andy,

tomorrow I'll try to bring more light into the dark.

klassikmann
RPI 3B + HifiBerry Digi+ Pro + RuneAudio+R e4
klassikmann

Posts: 158
Joined: 27 Apr 2016, 18:36

Re: RuneAudio+R e4

Postby AndyF » 29 Jul 2020, 19:37

Hallo klassikmann,

WinSCP is an explorer-like tool with SSH-access - it's worth a try for such copy-actions.

Regards, Andy
AndyF

Posts: 143
Joined: 02 Aug 2015, 07:36
Location: Germany - Bavaria
